Flux-cored wire WT-H580 (TM.WELTEC). TUU 28.7-31749248-005-2003

WT-H580

TUU 28.7-31749248-005-2003

EN 14700/ T Fe13

DIN 8555/ MF6-GF-60-G (suspended)

Welding process: О – open arc G – in shielding gas	Wire diameter, mm	Recommended shielding gases and fluxes
О	1,6-3,0	-
G	1,6-2,4	С1 (100% СО₂), М21 (18% СО₂ + 82% Ar)

General characteristics

It is designed for automatic and semi-automatic open-arc metal deposition of strengthening layers for wear-resistant surfaces that require increased hardness and corrosion resistance under conditions off hydro-abrasive and abrasive wear in combination with moderate impact loads.

Application

Typical applications are as follows: hard-facing of parts for slurry pumping stations, loading machines, coal pumps, dredgers and covers for pump housings.

Weldability

The Formation of the weld bead	good
Separation of Slag	good
Deposition Rate, kg/h	4-12
Addiction Weld metal Cracking	moderate
Consumption per 1 kg of wire Weld metal, kg	1.1-1.2
Weld metal Hardness (HRC for 3rd-4th layer, unless otherwise stated)	after surfacing 56-60

Technological features

It is recommended for metal arc deposition at direct current of reverse polarity - DC(+) using extended electrode wire stick-out.

Properties of the weld metal

Deposit composition (Weld metal), %

C	Mn	Si	Cr	B	S	P
0.9	0.5	0.9	11.0	0.7	0.013	0.015

Welding Alloys Analog

Brand of the wire	Distance, %	virobnik	C	Mn	Si	Al	Cr	Ni	Cu	Mo	S	P	Nb	V	N	W
ROBOFIL B P91 (75)	1.91	Welding Alloys	0.12	0.7	0.3	0.002	10	0.3	0.05	1	0.005	0.007	0.06	0.23	0.05
ROBODUR K CERAMIC-G (14)	2.38	Welding Alloys	0.35	0.7	2.5		9.5
CHROMECORE 410 (46)	2.52	Welding Alloys	0,07	0,6	0,2		13
CHROMECORE 420 (47)	2.52	Welding Alloys	0,30	0,8	0,6		13
CHROMECORE 414 COILER (45)	2.71	Welding Alloys	0,30	1,0	0,7		12	2,0		0,60						0,30

Recommended Surfacing Modes

Wire diameter, mm	Welding process:	Current, A	Voltage, V	Surfacing rate, m/h	Gas consumption l/min
1,6	O	140 - 240	24 - 28	10 - 15
1,6	G	120 - 320	23 - 32	10 - 15	7 – 15
2,0	O	160 - 260	25 - 28	12 - 18
2,0	G	150 - 400	24 - 34	12 - 18	8 - 16
2,4	O	200 - 320	26 - 29	15 - 20
2,4	G	180 - 450	25 - 36	15 - 20	10 - 18
2,8	O	240 - 360	26 - 30	18 - 23
3,0	O	260 - 400	26 - 30	18 - 23

Delivery type (More)

Wire diameter, mm	Cardboard barrel			Molded skeins of frameless type		Frame drum (B)	Coil (S), (BS)
	Cardboard barrel			Hank in the corrugation box	Metallic barrel	Frame drum (B)	Coil (S), (BS)
	To 100 kg	To 150 kg	To 300 kg	To 30 kg	To 70 kg	To 25 kg	To 15 kg
1.6	X	X	X	X	X	X	X
2.0	X	X	X	X	X	X	X
2.4	X	X	X	X	X	X	X
2.8	X	X	X	X	X	X
3.0	X	X	X	X	X	X
